AutoCAD Plot File Name Automation: Plot script/lisp utilizing Sheet Set Manager properties

Jake_CAD
Advocate
Advocate

Is it possible to write a script that plots all layouts in a file (or associated Sheet Set) with each file name compiled from title block field values (Based on attributes of Sheet Set Manager) in each individual layout?



For example;



Red = Sheet Set Property

Orange = Sheet Property



[1]-[2]-[3]-[4] [5] = 376-3-TD-100-00 GA Ground Floor - Detailed Proposal Plans











0 Likes
394 Views
2 Replies
Replies (2)
Message 2 of 3

baksconstructor
Advocate
Advocate

Please attach an example file .dwg.

Need a real .dwg example, your template is empty.
Your template has no fields, it is not clear what to output.

0 Likes
Message 3 of 3

baksconstructor
Advocate
Advocate


0 Likes
