Trouble with lattice work in the parametric window

15 ANTWORTEN 15
Antworten
Nachricht 1 von 16
tharushadd
2007 Aufrufe, 15 Antworten

Trouble with lattice work in the parametric window

Timber window.jpg

Hi,

I am very new to Revit.

Can anyone guide me how to model a parametric window family as in the attachment. I can model everything except for the timber lattice, there in the window as a component. I just want the lattice work to be 1"x0.5" timber stripes at an 45° angle ( That doesn't have to be parametric)

15 ANTWORTEN 15
Nachricht 2 von 16
dzanta
als Antwort auf: tharushadd

I would create those 4 panels as a 4 separate extrusions with a wood lattice model pattern (diagonal lines).  Ensure you align and lock the 4 sides to the reference planes that control the framework too.


Dzan Ta, AEE, ASM, ACI.

EESignature



Did you find this post helpful? Feel free to Like this post.
Did your question get successfully answered? Then click on the ACCEPT SOLUTION button.

EESignature


Autodesk Community | Twitter | YouTube | Facebook | LinkedIn |

Win 11 Pro/DELL XPS 15 9510/i9 3.2GHz/32GB RAM/Nvidia RTX 3050Ti/1TB PCIe SSD/4K 15.4" Non-Touch Display

Nachricht 3 von 16
barthbradley
als Antwort auf: tharushadd

Do you mean "muntins".  If so, Revit has a dozen or so Muntin Families in the OOTB library. Windows Folder=>Nested Families Folder=>Muntins Folder.



...you can also go to Pella or Marvin and download their Revit families.  Most have Muntins in them in all sorts of configurations (e.g. Prairie, Diamond, etc., etc.)

Nachricht 4 von 16
tharushadd
als Antwort auf: dzanta

Thank you very much, but how to have a 'wood lattice model pattern'...any video tutorial on internet...so that I can follow..

thanks again

Nachricht 5 von 16
dzanta
als Antwort auf: tharushadd

after you make the 4 extrusions, select them and go to properties palette...you will see material parameter.  click inside this to assign a Model material pattern....choose the diagonal line pattern


Dzan Ta, AEE, ASM, ACI.

EESignature



Did you find this post helpful? Feel free to Like this post.
Did your question get successfully answered? Then click on the ACCEPT SOLUTION button.

EESignature


Autodesk Community | Twitter | YouTube | Facebook | LinkedIn |

Win 11 Pro/DELL XPS 15 9510/i9 3.2GHz/32GB RAM/Nvidia RTX 3050Ti/1TB PCIe SSD/4K 15.4" Non-Touch Display

Nachricht 6 von 16
barthbradley
als Antwort auf: tharushadd

Still trying to figure out what is being talked about here.



Is it Lattice like this?








Or, Lattice like this (e.g. Muntins in a Diamond Pattern)?






Or, Lattice like this (e.g. Diagonal Crosshatch Surface Pattern)?






Nachricht 7 von 16
tharushadd
als Antwort auf: barthbradley

d.jpgActually something like this....as shown in the window drawing



T

Nachricht 8 von 16
barthbradley
als Antwort auf: tharushadd

I like the pattern. What is that? A screen?

Nachricht 9 von 16
tharushadd
als Antwort auf: barthbradley

Yes a screen...

Nachricht 10 von 16
barthbradley
als Antwort auf: tharushadd

A screen???  Well now...isn't that special.  Smiley (zwinkernd)



Church Lady.png

Nachricht 11 von 16
Anonymous
als Antwort auf: barthbradley

Barthbradley,

How would you actually create a modeled parametric lattice like the wood one here?

Seems simple but anything on a diagonal always complicates things.  I need to model this exact thing for a rendering of a "lattice top wood fence" - I'm thinking it would be a nested adaptive component??



The 45 degree lattice work would need to fit inside a rectangular boundary.

Nachricht 12 von 16
ToanDN
als Antwort auf: Anonymous

I would use a material with a diagonal cross surface model pattern instead of modeling it.
Nachricht 13 von 16
barthbradley
als Antwort auf: Anonymous





Are you talking about the wood lattice I showed above?  You could do this with a curtain wall. No panels, just mullions.  Maybe 1" x 1/2" slats, with beefier border mullion frame.  But if you are talking about the Screen you showed above, I'd find an OOTB "Metal Screen" Appearance Asset for Rendering, and then use a plain old cross hatch Surface Pattern for Elevation Views, etc.

Nachricht 14 von 16
Anonymous
als Antwort auf: ToanDN

Yeah, that's a bummer - I had my fence all parametric and ready to go, last was the parametric lattice.  If I had started it all as conceptual massing, I probably could have done it with dividing surfaces.  Oh well, that's a headache for some other time.  Guess I'll do a .PNG material with voids.

Nachricht 15 von 16
ToanDN
als Antwort auf: Anonymous

I thought you asked about windows.  If it is a fence, just use a curtain wall with panels by a different curtain wall type, and rotate the grids 45 degrees.

Still, there is no practical reason to model the lattice. A material with cut-out should work nicely.



Annotation 2019-03-01 155053.png





Nachricht 16 von 16
barthbradley
als Antwort auf: Anonymous

I think he means Curtain Walls with Empty Panels -- which is what I suggested.
