How can i remove Opening line from Window Family?

2 ANTWORTEN 2
GELÖST
Antworten
Nachricht 1 von 3
cadedu22
430 Aufrufe, 2 Antworten

How can i remove Opening line from Window Family?

Hello,



Probably easy one, but I can't figure it out.



Window opening-01.png

2 ANTWORTEN 2
Nachricht 2 von 3
RDAOU
als Antwort auf: cadedu22

@cadedu22



It is a nested component

  1. Open the Window Family you attached
  2. In Left or Right View Select the opening symbol and EDIT FAMILY
  3. Open the Right/Left view and delete the symbolic lines
  4. Reload back into the window



Window symbolic.gif



However, in case you need it for other types later, you do not need to Delete...you can give it a visibility parameter and switch it on and off in the project



Window symbolic1.gif

YOUTUBE | BIM | COMPUTATIONAL DESIGN | PARAMETRIC DESIGN | GENERATIVE DESIGN | VISUAL PROGRAMMING
If you find this reply helpful kindly hit the LIKE BUTTON and if applicable please ACCEPT AS SOLUTION


Nachricht 3 von 3
cadedu22
als Antwort auf: RDAOU

Thanks, somehow I didn't notice that it's nested, and was wondering why I can't access certain lines. Now it's clear.
