Silk Screen and Tracking Data Missing from PCB Assembly drawings & STEP/IGES Outputs

[Michael_Dalby6FK4J]

Hi All,

I have seen a few people asking this question previously and a fix was promised -  has the issue ever been fixed?

Some of the posts date back to 2019... In this Post @jorge_garcia suggest that a fix was on the way:  Solved: Re: STEP export does not export copper or silkscreen - Autodesk Community - EAGLE.

I have just tried it and it still seems to be an issue - which is bad for something that was promised 5 years ago.

This is the issue:

I see the silkscreen and track detail in the 3D view, but If I try to make a drawing from the 3D model (which has the silk screen present).....

..the output assembly drawing loses all of the track and silkscreen data:

This is also the same if I export the assembly as a step of IGES model - no Silk screen or track data .

Am I doing something wrong or has this not been fixed yet ?

Cheers, Michael

[jorge_garcia]

Hi @Michael_Dalby6FK4J ,

I hope you're doing well. I've answered your question on the other post you made.

https://forums.autodesk.com/t5/eagle-forum/step-export-does-not-export-copper-or-silkscreen/m-p/1289...

Let me know if there's anything else I can do for you.

Best Regards,
