Hello everyone!

Great News Community!  We have decided to  extend the deadline for submission by two weeks.  The new deadline is now Novemer 8th!  So get designing and join the game!

We are pleased to announce the Global Community Games 2020!  We will host two rounds of contests for the Design and Manufacturing industry in five language communities (English, French, German, Japanese, and Russian)!  The games are happening in Architecture, Engineering and Construction (AEC), and AutoCAD (ACAD) industry/product in the eight language communities also!

The first round is the Preliminary Competition - Design and Manufacturing.  All the contestants must start from here to become the winner in your community.  The top two from each language community will proceed with the Global Competition Final- Design and Manufacturing.  They will compete with the 9 winners from the other language community to win the Championship.

Awards*:

	Preliminary Competitions	Global Competitions Final
1st	400 USD worth US Amazon Gift Cards	1,000 USD worth US Amazon Gift Cards
2nd	200 USD worth US Amazon Gift Cards	600 USD worth US Amazon Gift Cards
3rd	N/A	400 USD worth US Amazon Gift Cards

*Note: Awards are in US Dollars for English Community.  The Awards for French, German, Japanese, and Russian Communities are local currency equivalent Gift Cards.

Community	Awards
English	Amazon Gift Cards- Australia Amazon Gift Cards- US Amazon Gift Cards- UK Amazon Gift Cards-Canada
French	Amazon Gift Cards- France
German	Amazon Gift Cards-Germany
Japanese	Amazon Gift Cards-Japan
Russian	OZON.ru gift cards

Key Dates in Pacific Standard Time

Event	Preliminary Competitions	Global Competitions Final
Start	Sep 25, 2020	Oct 31, 2020 Nov 17, 2020
Submit the design by	Oct 25, 2020 Nov 8, 2020	Dec 06, 2020*
Winner Announcements	on/around Oct 30, 2020 Nov 16, 2020	on/around Dec 11, 2020

*Note: It’s up to finalists to re-work on the original design for the Global Competitions Final to be their best and re-submit before the final deadline.

Rules:

1. Must be 18 years old and up at the time of submission of the design.
2. Must be an Autodesk Community Member
3. Residents or citizens of Brazil, Argentina, Poland, Romania, Italy, Turkey, or any US embargoed country will be excluded.
4. Must read and agree on Official Rules-D&M and the privacy statement.
5. By submitting your entry to this topic as a reply, you agree to the Contest Official Rules and to the use of your personal information as described in the Autodesk Privacy Statement.
6. One submission per person per Architecture, Engineering and Construction (AEC), Design and Manufacturing (D&M), and AutoCAD (ACAD).  You cannot apply both AutoCAD English and AutoCAD German, but you may do so at both AEC English and AutoCAD German, for example.

How to enter your design:

It’s simple and easy. Just reply to this topic with your design.

Judging Criteria:

Autodesk Community Managers and the Autodesk Technical Staff will be the judge.

Industry	Judging Criteria
Design & Manufacturing (D&M)	Innovation, originality, and modeling technique

For those who want to join without submitting the design:

Don’t worry, you can vote for the design you like using the “Like” button.  You need to Sign in to participate.  The votes won’t be one of the judging criteria, but we want to hear from you.

Finally, here's the Challenge!

Design & create a working assembly of a simple mechanism.  Make it as simple or complex as you would like.

• Use either Fusion 360 or Inventor.
• Attach the assembly and all native files required to open the assembly as a ZIP file ( you may use Pack n Go, but please keep in mind the maximum file size to attach is 72 MB).
• Embed into your submission a Screencast recording of the mechanism in motion to prove that it works.

We are looking forward to seeing your design!  Enjoy!

Check out the other industries and vote (or even participate if you can)!

Architecture, Engineering and Construction (AEC)

AutoCAD (ACAD)

[CGBenner]

@Anonymous

Hi, the video did not attach.  If you are unable to embed it in to the message, you may post a link.  Thanks!

[graemev]

One small addendum to my submission:

Photographs of the actual 3D printed model. (Yes, folks, it works as advertised.)

Judges,

Please note that clearances in the model are deliberate for purposes of 3D printing in SLS nylon-12 for all parts excepting the bushings, which are multi-jet fusion acrylic.

[SirishaShashikanth]

Hello all,

  Here's my entry

 A drop of love - Mechanical Automata toy. This comes with a message of peace.

A drop of love and forgiveness can create the same ripples around them and make the world a better place to live.

The whole idea has been brought to shape using Fusion 360 software.

Water droplet automata is a popular toy depicting the ripple effect of a drop. A new automata toy by replacing the circular shape of ripples with the shape of a heart has been conceived.

A drop of love CAD Model

Another render

Screencast - Check the model in Action

Here are the images and render links

https://mechatheart.com/a-drop-of-love-renders/

Motion study

https://www.instagram.com/p/BvJm-gknkBp/

@CGBenner

[Anonymous]

I'm sorry, I hope this message contains the video, but I'm not sure I understand this whole "screencast + reply in forum" thing.

Here is the link to another version of the video: https://autode.sk/37YACp1

[rushabhthakkar_910]

Yes Sir, the Video is Visible Now......

[rushabhthakkar_910]

---

@JuanMuñoz711 wrote:

Im sorry, I hope this message contains the video, but I'm not sure I understand this whole "screencast + reply in forum" thing

And Ya, it's Simple... When you Reply in the Forum, you have Options to Attach some files and also to attach a Screencast....

For Screencast, you can either paste the Link or Browse the Screencast from your Contributions.....

It's available just below the write-up in the Reply....

[Anonymous]

Thank you! I edited the reply just now with a link from youtube

[rushabhthakkar_910]

The Screencast was Visible sir..... No issues you edited it with a YouTube Video and the Link to Screencast....

It's just that you said you did not understand the Screencast + reply thing, so I just tried to explain it.... 🙂

[Anonymous]

Silk pinching lacquer ware (hereinafter referred to as lacquerware) is a kind of painting method in which gold and silver or other metal filaments are pinched into patterns according to the bending and turning of ink patterns, and are glued onto the lacquer board made of natural lacquer as the main material. It is one of the intangible cultural heritage of China. However, due to the fragility and fluidity of the paint layer on the surface of the lacquer board, the CNC machine tools on the market can not process the lacquer board, which leads to the lacquerware processing still mainly by hand, and the efficiency is very low.

The CNC machining system developed by us is a three axis CNC equipment based on the characteristics of lacquer board. In terms of structure, in view of the vulnerability of the paint layer, we have developed an adjustable flexible fixture, which can be used to hold different sizes and thicknesses of paint plates on the basis of protecting the paint layer. In view of the fluidity of the paint layer, we refer to the processing method of the traditional manual thread pinching lacquer ware, and design our product into a vertical structure, which is helpful for the timely discharge of processing waste. In the software, we use the Mach3 control system, and on the basis of the secondary development, designed a special control system and control interface, more convenient for users to operate. In terms of function, the product can be used for slotting paint layers of different sizes and thicknesses, reducing the difficulty of wire pinching process, and replacing the cutter head with a grinding head, which can be used for the lacquering process of lacquerware and assisting the production of lacquer board.

Compared with traditional processing methods, our products can reduce processing time, liberate manpower and reduce costs. I believe our products will affect the whole lacquer industry.

[Rathanpm]

So when I saw this competition, I thought about a concept that has been rolling around my head.

It was inspired by a Reddit post that I had seen a while ago, about an auto repair guy tuning a Porsche 911 that someone had brought in.

This particular Porsche had an interesting quirk, rear wheel steering. This feature supposedly helps with speed and traction around a track, but I was more interested in the dynamic movement.

So I made this model for this competition, hope you guys like it.

(All work is original, I'm especially proud of the car body, my first real venture into the mesh workspace)

@CGBenner

[Rathanpm]

I don't think the screencast is not showing up in my previous post, so here's a link aswell:

https://autode.sk/328r0nQ

[Rathanpm]

Figured it out. Sorry for the triple correspondence, its getting late, and I've been on the computer too long. I just didn't see the insert button.

https://autode.sk/328r0nQ

b64c3af6-b782-4b0c-89d0-bec7580852fd,height=undefined,

[Anonymous]

In decorating an industry, the installation that wall decorates plank is important component, basically use large glass material, these material weight sink, dimension is big, easy break, scaffolding and auxiliary facilities need to be erected in construction process, need numerous installation worker, installation process difficulty is tall, safety is poor. This is based on the above design of a large glass auxiliary installation manipulator, automatic identification of the position of the glass, and then to grasp the glass adsorption, so as to achieve the capture, handling, installation of large glass panel mechanization and auxiliary automation operation, save labor, make the glass installation more safe and labor-saving.

EDITED by Moderator: Video is embedded in .rar file

[Anonymous]

Three axis CNC screw lock machine we will use a double table mechanism, greatly improve the efficiency of locking screw, screw positioning using visual recognition system, so that positioning more accurate, the machine will use three weeks screw module, in all directions can be accurate locking screw, to fill the current gap in the domestic market.

Edited by Moderator - Video is embedded in .zip file

[Anonymous]

This is a model of a three-axis printer. The movement of chassis and dispensing machine is controlled by motor and crawler.

EDITED by Moderator: Video is embedded in .zip file

[Anonymous]

Component model presentationComponent model presentation2

The automatic disinfection and packaging system designed by us can effectively reduce the contact between doctors and patients with infectious waste and improve safety. At the same time, there is no need for collectors to wear multiple protective clothing to collect infectious waste. Our automatic packaging system can automatically pack and dispose the garbage, and carry out secondary disinfection on the outside of the packaging bag, and use goose neck sealing bag to reduce the possibility of leakage as far as possible. At the same time, the project belongs to the field of intelligent scientific and technological machines, ecological environment protection, energy conservation and emission reduction. This field integrates intelligent control system design, mechanical structure design and Internet of things, which is suitable for various electronic application fields. With the economic growth, the improvement of residents' consumption level and environmental protection awareness, the automatic disinfection and packaging system of medical infectious waste will be in the future Life is playing an increasingly important role.

[Anonymous]

Hello, director. It's a pleasure to be here. This is my design of a small simple mechanical arm, the drill is connected by hinges, while the arm body has multiple links, can achieve multi-directional movement. Drill bit with magnetic adsorption, can grasp any irregular small objects

[Anonymous]

In my previous post, the screencast was not shared. Here it is!!!

Re-post:

This is a simple mechanism of how a bird flaps its wings. The focus is to showcase the design mimicking the nature.

<iframe width="1280" height="990" src="https://screencast.autodesk.com/Embed/Timeline/7bd38a77-e8da-478b-bd4e-4dd4daac2073" frameborder="0" allowfullscreen webkitallowfullscreen></iframe>

[1165236169]

Here is my work. Through the cross-over wing design， it folds to a high degree. And the inspiration for appearance design is from Green Flower Porcelain, actually it is a kind of  porcelain  date back to ancient Chinese.

[Anonymous]

I'll arrange it as soon as possible, Sir
